RV-M series
The RV-M300 microfocus industrial CT detection system is a high-resolution industrial CT system that can use a 160-300kV microfocus X-ray source. The system meets the high-resolution detection requirements for samples of various sizes and densities. The detection resolution of the system can reach the micro nano level, and can complete various tasks such as internal structure analysis of samples, assembly accuracy detection, size and tolerance measurement, and reverse engineering. The system can be equipped with dual radiation sources to meet customer testing needs.
Related Products
| Model | RV-M300 |
||||
| X-ray tube | Tube type | Open the tube | |||
|
Voltage |
160kV | 225kV | 240kV | 300kV | |
| Tube current | Transmission target | Transmission target | Reflective target | Reflective target | |
|
Focus size（JIMA resolution） |
0.5μm | 0.9μm | 2μm | 3μm | |
|
Flat panel detectors |
Pixel size | 49.8μm/100μm | |||
| Pixel matrix | 2340x2813/4260x4260 | ||||
| Valid area | 116.5mmx140mm/426mmx426mm | ||||
| A/D conversion | 16bit | ||||
|
Mechanical scanning platform |
Maximum FDD focal length | Up to 800mm | |||
| Dimensions of the mechanical structure | 2000mm×1600mm×1400mm（Customizable） | ||||
| Lead room system | Dimensions (W×D×H) | 2750×1900×2200mm（Customizable） | |||
| Test the sample | Maximum sample size (ØxH) | 380mm×500mm（Customizable） | |||
Meet various size detection needs
Fully automatic scanning, easy to operate
Equipped with an 8-axis high-precision mechanical system
Customization can be achieved according to user needs
Independently developed software system, fast image reconstruction speed, and high image quality
